Mimosa Backhaul B5 User Manual

Mimosa Backhaul Help Content
Mimosa Backhaul SNMP Interface
Copyright © 2014 Mimosa Page 173
Radio Information
Chains Table
OID Object Output Example UI Location
1.3.6.1.4.1.43356.2.1.2.6.1 mimosaChainTable Formatted Table Overview > Dashboard > MIMO
Status > Chains
1.3.6.1.4.1.43356.2.1.2.6.1.1.2.1 mimosaTxPower.1 INTEGER: 10 dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 1 > Tx
Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.2.2 mimosaTxPower.2 INTEGER: 10 dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 2 > Tx
Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.2.3 mimosaTxPower.3 INTEGER: 10 dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 3 > Tx
Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.2.4 mimosaTxPower.4 INTEGER: 10 dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 4 > Tx
Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.3.1 mimosaRxPower.1 INTEGER: -500
dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 1 >
Rx Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.3.2 mimosaRxPower.2 INTEGER: -500
dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 2 >
Rx Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.3.3 mimosaRxPower.3 INTEGER: -500
dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 3 >
Rx Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.3.4 mimosaRxPower.4 INTEGER: -500
dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 4 >
Rx Power
1.3.6.1.4.1.43356.2.1.2.6.1.1.4.1 mimosaRxNoise.1 INTEGER: -800
dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 1 >
Rx Noise
1.3.6.1.4.1.43356.2.1.2.6.1.1.4.2 mimosaRxNoise.2 INTEGER: -800
dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 2 >
Rx Noise
1.3.6.1.4.1.43356.2.1.2.6.1.1.4.3 mimosaRxNoise.3 INTEGER: -800
dBm
1
Overview > Dashboard > MIMO
Status > Chains > Chain 3 >
Rx Noise
