ASSEMBLY INSTRUCTION

Secure the pole (C) to the base support (G),

using bolts and nuts (aa) and spanner (bb).

Secure the connecting elbow (H) to the

pole (C), using bolts and nuts (aa) and

spanner (bb).

Secure the connecting elbow (H) to upper

beam (B), using bolts and nuts (aa) and

spanner (bb).

Secure the upper beam (B) to the square

tube hook (I), using bolts and nuts (aa)

and spanner (bb).

Step 6 Step 7

Step 8 Step 9

#H

#C

#aa

#aa

#H

#B

#I

#B

#aa

#bb

#bb

#aa

#bb

#aa

#bb

#bb

#bb
