15. Specification | 15.5 - Mechanics | 143
15.4.5 Connecting cables
Connection PR no./cable type Length
between junction box
and device
PR 6135, PR 6135A max. 500m – length
of the load cell cable
15.5 Mechanics
15.5.1 Housing
Material Polyamide
Surface finish Untreated
Color (RAL) Light gray (7035)
UL 94 flammability class V0
Dimensions See Chapter Housing di
mensions
Weights Net weight
Shipping weight
approx. 274 g
approx. 418 g
