3−3. Installation
 ● When installing the instrument, install as the following figures and
secure the space around the instrument.
Each dimensions of the instrument and required dimensions for the environmental spaces are as
follows:
Outline dimensions
Front
Side
Unit：mm
43
4
4
67
208
200
140.7
185
