IV
(2) Installation
 ● When installing the instrument, install as referring to the following
figures and secure the space around the instrument.
Each dimensions of the instrument and required dimensions for the environmental
spaces are as follows:
Outline dimensions
Front
Side
Unit：mm
43
4
4
67
208
200
140.7
185
