Minebea CSD-891B - Page 68

54
Procedures
Transmit the maximum display value change
command data from the host, and set the
maximum display value. The setting range of the
maximum display value is (The minimum digits
×100)〜99 999. To use the performance
effectively, set the value within the following
range. If you set the value exceeding the
following ranges, there may cause the unstable
displays, etc.,
The maximum display value
2 4 6 8 10 12 14
@ 0 0 1 1 2 0 0 0 Termi
ID No.
Command Host→CSD−891B
Return CSD−891B→Host
Nl
ii
-nator
3
The maximum display
value setting range
100〜10 000
200〜20 000
500〜50 000
1 000〜99 990
The minimum
digits
1
2
5
10
 Don’t attach the decimal point to the
setting value in the command data.
The display of the load display section displays
“−RS−” and “S MV” alternately.
 The setting value in the command data is
put from the right, and an unnecessary
space is given as space.
2 4 6 8 10 12 14
@ 0 0 1 1 2 0 0 0 Termi
ID No.
・Normal termination
The maximum display value
2 4 6 8 10 12 14
@ 0 0 1 1 E R - 2 Termi
ID No.
・Set in error
The maximum display value
-nator
-nator
