53
 ● This calibration method is possible when the optional RS−232C
interface or the RS−422/485 interface is mounted.
● When RS−232C interface is used, the ID No. becomes “00”.
● During the calibration, to interrupt the calibration “Calibration mode
interruption command” is transmitted, or press the  key.
The calibration data is kept as before entering the calibration and
returns to the measurement mode.
@ 0 0 0 0 Terminator
246
@ 0 0 0 0 Terminator
2468101214
Command Host→CSD−891B
Return CSD−891B→Host
ID number
ID number
Procedures
1
Transmit the calibration mode start command
from the host.
The display in the load display section displays
“−RS−” and “SCAL” alternately.
246
@ 0 0 0 1 Terminator
Command Host→CSD−891B
2 4 6 8 10 12 14
@ 0 0 0 1 C C A L Termi
ID No.
Return CSD−891B→Host
ID No.
-nator
2
Transmits the minimum digits change command
data from the host, and set the minimum digits.
The setting value of the minimum digits is
following four kinds.
1, 2, 5, 10
The display of the load display section displays
“−RS−” and “DISP” alternately.
 Don’t attach the decimal point in the
setting value in the command data.
 The setting value in the command data is
put from the right, and an unnecessary
space is given as space.
The minimum digits
2 4 6 8 10 12 14
@ 0 0 1 0 1 Termi
ID No.
Command Host→CSD−891B
2 4 6 8 10 12 14
@ 0 0 1 0 1 Termi
ID No.
Return CSD−891B→Host
The minimum digits
-nator
-nator
