4 Connect the power cable to the fuse box.
5 Crimp the fuse spade onto the power wire and slide the fuse tap over one metal prong of the fuse.
6 Slide the fuse spade over the fuse tap and then put the tapped fuse back in the fuse box; make sure that the
tapped side of the fuse is placed in the unpowered (accessory) side of the fuse socket (see step 3).
7 The black ground wire inside the power cable is not required.
8 Connect the power cable to the adapter and then slide the adapter plug switch to KEY.
9 Run the HDMI cable under the dash or weather stripping. This is discreet, stylish and will help protect the Mini
Maxx.
SECTION 8: MOUNTING THE MINI MAAX
1 After cleaning and drying the windshield, select a safe place to mount the Mini Maxx. Be sure not to obstruct the
driver’s view when choosing the location.
2 Stretch out the HDMI cable to make sure reach the Mini Maxx with a small amount of slack.
3 Use the T-slot on the back of the Mini Maxx to attach it to the Universal Windshield Mount (UWM).
4 Position the UWM suction cup on the windshield and press the lever on the base of the mount towards the
windshield to secure it in place
