Displays
Vehicle equipment
All standard, country-specific and optional
equipment that is offered in the model series is
described in this chapter. Therefore, equipment
is also described that is not available in a vehi‐
cle, e. g., because of the selected optional
equipment or country variant. This also applies
for safety-related functions and systems.
Instrument cluster
Overview, instrument cluster
1 Tachometer 74
2 Indicator/warning lamps 72
3 Speedometer
4 Fuel gauge 74
5 Display/reset miles 74
6 Electronic displays 72
Seite 71
Displays
CONTROLS
71
Online Edition for Part no. 01 40 2 927 905 - II/14
