Release the handle.
Press the wind deflector downward,
while inserting the pins in the corre-
sponding mounting points, arrows 2.
5. Press the wind deflector downward in
the middle, until the handle engages, ar-
rows 1.
Grasp the inner framework of the wind
deflector and fold it up, arrow 2.
Removing
1. Fold the handle up to unlock it.
2. Proceed in reverse order to remove the
wind deflector.
Seite 83
Opening and closing CONTROLS
83
