Operating via
touchscreen
General information
The Control Display is equipped with a
touchscreen.
Touch screen with your fingers. Do not use any
objects.
Opening the main menu
Tap on symbol.
All onboard monitor functions can be called up
via the main menu.
Selecting menu items
Tap desired menu item.
Menu items in the Owner's Manual
In the Owner's Manual, menu items that can be
selected are set in quotation marks, for in‐
stance "System settings".
Changing between panels
After a menu item is selected, a new panel is
displayed.
The arrow indicates that additional panels can
be opened.
▷ Swipe to the left.
▷ Tap on symbol.
New display is opened.
Opening recently used menus
1.
Tap on symbol.
2. Tap on symbol.
Changing settings
Settings such as volumes can be changed via
the touchscreen.
▷ Slide in the selected field to the right or left,
until the desired setting is displayed.
▷ , Tap on symbol.
Activating/deactivating the functions
Several menu items are preceded by a check‐
box. It indicates whether the function is acti‐
Seite 22
AT A GLANCE
Onboard monitor
22
Online Edition for Part no. 01 40 2 976 545 - X/16
