Tail lights, bulb replacement
Overview
1 Tail lights in split doors
2 Tail lights in bumpers
3 License plate light
4 Center brake light
Tail lights in split doors
Note the safety information on lights and
bulbs, refer to page 292.
Overview
1 Turn signal
2 Tail lights
3 Rear fog light
4 Reversing lights
Turn signals
21-watt bulbs, P21W.
1. Open the split doors.
2. Remove left or right cover. If necessary,
it is then possible to pry the cover off
using a screwdriver or a similar plastic
tool.
3. Press the latches together upward, ar-
row 1, and remove the bulb holder.
Loosen the plug connector, arrow 2, on
the bulb holder.
4. Remove the bulb holder from the open-
ing.
Seite 295
Replacing components MOBILITY
295
