5. Press the nonworking bulb, arrow 1,
gently into the socket, turn counter-
clockwise and remove.
6. Proceed in the reverse order to insert
the new bulb and attach the bulb holder.
Make sure that the bulb holder engages
in all fasteners.
Rear fog lights/reversing lights
21-watt bulbs, P21W.
1. Open the split doors.
2. Remove left or right cover.
3. Press the latches together in the direc-
tion of the arrow, arrow 1, and remove
the bulb holder.
Loosen the plug connector, arrow 2, on
the bulb holder.
4. Remove the bulb holder from the open-
ing.
5. Press the nonworking bulb gently into
the socket, turn counterclockwise and
remove.
– Arrow 2: rear fog lights.
– Arrow 3: reversing light
6. Proceed in the reverse order to insert
the new bulb and attach the bulb holder.
Make sure that the bulb holder engages
in all fasteners.
Tail lights in split doors, Union Jack
All lamps in the split doors feature LED
technology.
In the case of a malfunction, contact a deal-
er's service center or another qualified serv-
ice center or repair shop.
Tail lights in bumpers
Follow the general instructions on lights
and bulbs, refer to page 292.
Seite 296
MOBILITY Replacing components
296
Online Edition for Part no. 01402666575 - VI/19
