Minium Amp - Technical Specifications; CD, Amplifier, and FM Data; Product Guarantee Information

TECHNICAL DATA GUARANTEE E
16
CD
Typical Audio Performance
Frequency range (0 / - 0.5dB) : ............. 2Hz - 20kHz
Linearity on - 90 dB : .................................. < 1.5 dB
Signal-to-noise ratio : ................... < - 80 dB at 1 kHz
Channel separation : .................... > 100 dB at 1 kHz
D/A conversion : .................................. 5 bit / 128 Fs
Audio output level : ................................ 2Vrms / 0 dB
Output impedance : ......................................... 200Ω
Power supply.
Power consumption : ....................................... 11 W
Fuse............................. T 160mA / 250V (Slow blow)
T 315mA / 130V (Slow blow)
Dimensions : w x d x h in mm ......... 430 x 265 x 70
Weight : ........................................................ 4.0 kg
FM
Typical Audio Performance.
Wave range FM : ............................. 87.5 - 108 Mhz
Sensitivity at 75 Ω :
mono, 26 dB S/N : ..................................... 1.1µV
stereo, 50 dB S/N : ..................................... 45µV
Selectivity : .................................... 60 dB at 300kHz
Distortion THD mono : ................................. ≤ 0.5 %
Distortion THD stereo : ................................. ≤ 0.7 %
Frequency range (± 1.5 dB) : ............. 30 Hz - 15 kHz
Signal/noise ratio (mono/stereo) : ........ 74 dB / 70 dB
Power supply.
Power consumption : ....................................... 10 W
Fuse............................... T 200mA/250V (Slow blow)
T 315mA/130V (Slow blow)
Dimensions : w x d x h in mm ............ 430 x 275 x 70
Weight : ......................................................... 4.0 kg
AMP
Typical Audio Performance.
Power ( 8 Ω ) : ............................................ 2 x 40 W
Output impedance : ................................ 0.1 Ω / 1kHz
Bandwidth (40 W / 8 Ω) : ................... 20 Hz - 30 kHz
Sensitivity / impedance :
CD input : .......................... 280 mV / 47.5 kΩ
PHONO input : ..................... 18 mV / 47.5 kΩ
Impedance / gain monitor output : ........ 120 Ω / 0 dB
Distortion THD ( 20 Hz / 20 kHz ) : ............... < 0.1 %
Signal to noise ratio : .................................. > 90 dB
Power supply.
Power supply : ............................................... 220 W
Fuse................................... T 1.6A / 250V (Slow blow)
T 3.15A / 130V (Slow blow)
Dimensions : w x d x h in mm .......... 430 x 295 x 70
Poids : .......................................................... 6.5 kg
WARRANTY
Micromega S.A. warrant the product contained herein
to be guaranteed against manufacturing faults and
defectcs for a period of 2 years ( 1 year for the CD
mechanism ) from the purchasing date.
For warranty work the unit must be returned to the
vendor with a copy of the original sales receipt.
The warranty will be invalid should the unit be :
- Damaged by accident.
- Damaged by negligence.
- Damaged by miss - use.
- Damaged by miss - installation.
- Damaged by tempering by a non - appointed agent.
- Damaged by transit.
You shoud contact your vendor in your country of
purchase with regards to specific local warranty
details.
