4
BLADE INSTALLATION
Align the 3 holes from the blade to the
fan motor.
Secure blade with 3 blade screws with locked washer
provided. Follow the same process for the remaining
two blades. (Fig. 5)
All blade sets are grouped together by weight.
Step 2. Align holes in the flywheel and the fan motor
assembly, and secure with the screw. Ensure all the
screws are tightened. (Fig. 6)
Step 1.
Fig. 6
Screw
Fan motor
Fig. 5
Fan motor
Screw
Blade
Flywheel
To Next Page
