12v battery
RED+
120V AC
I
NPUT
BLACK-
S
INGLE CHANNEL
BATTERY CHARGER
12v battery
R
ED+
1
20V AC
INPUT
BLACK-
TWO CHANNEL
BATTERY CHARGER
12v battery
R
ED+
BLACK-
12v battery
RED+
120V AC
INPUT
BLACK-
THREE CHANNEL
BATTERY CHARGER
12v battery
RED+
BLACK-
12v battery
RED+
BLACK-
7
NOTE: If batteries are connected in
series for 12/24 - 24V, the series
connection wire should be left in
place during charging.
NOTE: If batteries are connected in
series for 12/24 - 24 - 24/36 - 36V, the
series connection wire should be left
in place during charging.
