NAMES OF PARTS
10
GETTING STARTED
Continued on next page.
* This camera is a sophisticated optical instrument. Care should be taken to keep these
surfaces clean. Refer to the care and storage section at the back of this manual (p. 55).
BODY
The quartz-date model is illustrated.
Flash* (p. 32)
Self-timer/Remote-control
lamp* (p. 41, 52)
Lens*
Back-cover release (p. 17)
Manual-rewind button (p. 31)
Remote-control
receiver* (p. 50)
(Quartz-date model only)
Viewfinder window*
Tripod socket
Shutter-release button (p. 22)
Data panel (p. 12)
Viewfinder* (p. 13)
Date button (p. 44)
(Quartz Date model only)
Flash-mode/Select button
(p. 32, 44)
Main switch (p. 20)
Film window (p. 17)
Strap eyelet (p. 14)
Battery-chamber
door (p. 15)
Zoom lever (p. 21)
Back cover (p. 17)
Drive-mode/Adjust button
(p. 40, 42, 44, 51)
Meter window*
AF window*
