CONTINUED - WOODWORKS: ADVANCED PROJECT 2009-2010 PATIO TABLE
tOOlS RequiReD
Hand Tools
– Sanding block
Power Tools
– Table saw
– Router
– Shaper or table-mounted router
– Drill press
– Jig saw
– Power drill with drill bits, Phillips-head
screwdriver bit, and 1/4" socket driver
– Hole saw
– Orbital or finish sander
– Drum sander
– Belt sander
– Band saw
Miscellaneous
– Pencil
– Tape measure
– Safety glasses
– 120-grit sanding belt
– 120-, 150- and 220-grit sandpaper
– Clean, lint-free cloths
– Respirator
– Gloves for finishing
– Mineral spirits, for oil-based
waterproofer
– Good quality, natural-bristle brush
(for oil-based waterproofer) or
synthetic-bristle brush (for water-based
waterproofer)
– Cotton-tipped swabs
– Acetone
– Rustproof paint
SHOppinG liSt
Wood Recommendation: Pine
Alternate Wood: Cedar
Part Dimensions Qty.
A, B, C 1" x 5-1/2" 5 @ 8', 1 @ 10'
E, F 1" x 7-1/2" 1 @ 3'
D, G, H, J 2" x 5-1/2" 1 @ 8', 1 @ 10'
K 1/8" x 1-1/2" x 6" steel plates 4
L 1/4" x 5" x 1" 24 from scrap
Wood screws #10 x 2" flathead stainless steel 24
Lag bolts 1/4" x 1" stainless steel 8
Lag bolts 1/4" x 4-1/2" stainless steel 4 w/ washers
cuttinG liSt
Overall dimensions: 29-3/4"H x 44" Dia.
Part Name Qty. Th x W x L
A Ring Segment 12 1" x 4" x 11-15/16"
B Top Slat 24 1" x 4-3/4" x 15-7/8"
C Hub Segment 4 1" x 4-1/2" x 8-1/2"
D Strut 4 1-5/8" x 1-5/8" x 18-1/2"
E Outer Brace 4 1" x 1-5/8" x 21-7/8"
F Inner Brace 4 1" x 1-5/8" x 5"
G Lower Ring Segment 4 1-5/8" x 5-1/4" x 12"
H Upper Leg 4 1-5/8" x 4" x 11-1/2"
J Lower Leg 4 1-5/8" x 4" x 22"
K Steel Bracket 4 1/8" x 1-1/2" x 6"
L Spline 24 1/4" x 5" x 1"
WOOD FiniSHinG pRODuctS
Recommended Finish
Stain/Finish: Thompson’s
®
WaterSeal
®
Advanced Tinted
Wood Protector Sheer Honey Gold
Alternate Finish
Stain/Finish: Thompson’s
®
WaterSeal
®
Waterproofer Plus
Tinted Wood Protector Sheer Honey Gold
