MA-708(CHAR) TEST AND ALIGNMENT INSTRUCTIONS
NO
MEASUREMENT
ADJUSTMENT
SIGNAL INPUT
PREPARATION
UNIT SETTING
TESTPOINT ADJUSTER
NORMAL
VALUE
1
Charge saturation
Voltage
DC power supply:
32V(J8 INPUT)
DC Voltmeter J10 VR2 29.1V±0.2V
2 Current Limit
DC power supply:
32V(J8 INPUT)
B2:8Ω LOAD
Current meter J10
480mA
±30mA
3
Saturation Current
Limit
DC power supply:
32V(J8 INPUT)
B2:40Ω LOAD
Current meter J10
300mA
±150mA
J15 VR3
14.25V±0.25V
4 Saturation LED
DC power supply:
28.5V(J8 INPUT)
DC Voltmeter
J10 ≥27.5V
J15 VR3 0V±0.25V
5 Charging LED
DC power supply:
32V(J8 INPUT)
DC Voltmeter
J10 ≤28.5V
6 32V Current
DC power supply:
32V(J8 INPUT)
DC Voltmeter J11 32V±01V
A708R03B
