Mipro MA-708 - Page 56

CIRCUIT
：
1PA035A3 A708P01B
PART LIST
COMPUCTOR NO. REFETENCE VALUE
1CENCA476 C1 220U/25VE
1CENCA476 C2 47U/25VE
1CEMEA226 C3 22U/50V
1DLNRC04 LED1 LED4
1SFHB02A P1 2PIN
1SFHC02B P3 PINAC2
1SFHC02B P4 PINAC2
1SFHC02B P5 PINAC2
1SFHC02B P6 PINAC2
1SFHC04B P7 PINAC4
1TS02412 Q1 1TS02412
1TS01037 Q2 1TS01037
1TS02412 Q3 1TS02412
1TS02412 Q4 1TS02412
1TS01189 Q5 1TS01189
1TS01037 Q6 1TS01037
1RS6A563 R1 56K
1RNC0101 R2 100
1RS6A123 R3 12K
1RS8B224 R4 220K
1RS6A103 R5 10K
1RS8B047 R6 47
1RS8B047 R7 47
1RS6A223 R10 22K
1RS6A223 R11 22K
1RS8B472 R12 4.7K
1RS6A103 R13 10K
1RS8B622 R14 6.2K
1RS8B822 R15 8.2K
1RS8B822 R16 8.2K
1RS8B622 R17 6.2K
1RS8B822 R18 8.2K
1RS6A047 R19 47
1SRC0003 RL1 1SRC0003
1DVS4007 Z1 1DVS4007
1DVS4007 Z2 1DVS4007
1DDS4148 Z3 1DDS4148
COMPUCTOR NO. REFETENCE VALUE
1DDS0204 Z4 1DDS0204
1DDS0451 Z5 1DDS0451
