Mipro MA-708 - Page 57

CIRCUIT
：
1PA046C2 A708P01B
PART LIST
COMPUCTOR NO. REFETENCE VALUE
1CCS8X104 C1 104P
1CTSBA106 C2 10U/16V
1CESCE106 C3 10U/25VS
1DLNA004 LED1 1DLNA004
1SFVB03A P1 1SFVB03A
1SFHB05B P2 1SFHB05B
1SFVB02A P3 1SFVB02A
1TS01577 Q1 1TS01577
1RS8B222 R1 2.2K0
1RS8B222 R2 2.2K0
1RS8D123 R3 120K
1RS8D123 R4 120K
1RS8B103 R5 10K
1RS8B103 R6 10K
1RS6A473 R7 47K
1RS6A473 R8 47K
1RS6A473 R9 47K
1RS6A473 R10 47K
1RS6A244 R11 240K
1RS8B222 R12 2.2K0
1RS8B222 R13 2.2K0
1IN07551 U1 1IN07551
1IS16819 U2 1IS16819
1DCSU120 Z1 1DCSU120
1DDS0014 Z2 1DDS0014
1DDS0014 Z3 1DDS0014
1DDS0014 Z4 1DDS0014
1DDS0047 Z5 1DDS0047
1DDS0451 Z6 1DDS0451
