Mipro MA-708 - Page 58

CIRCUIT
：
1PA067B1 A708P01B
PART LIST
COMPUCTOR NO. REFETENCE VALUE
1CTSBA225 C1 2.2U/25V
1CTSBA225 C2 2.2U/25V
1CENCA106 C3 10U/25VE
1CCS6X102 C4 102P
1CENEA226 C5 22U/50V
1CTSBA106 C6 10U/16V
1CTSBA475 C7 4.7U/20V
1CTSBA475 C8 4.7U/20V
1CCS6P331 C9 330P
1CCS6P331 C10 330P
1CCS6X104 C11 104P
1CCS6X104 C12 104P
1CTSBA225 C13 2.2U/25V
1CCS6P331 C17 330P
1SFVB07B P1 1SFVB07B
1TS01577 Q1 1TS01577
1TS00508 Q2 1TS00508
1TS00508 Q3 1TS00508
1RS6D103 R1 10K0
1RS6D103 R2 10K0
1RS6A563 R3 56K
1RS6A563 R4 56K
1RS6D114 R5 110K
1RS6A027 R6 27
1RS6D102 R7 1K0
1RS6A225 R8 2.2M
1RS6D104 R9 100K0
1RS6D104 R10 100K0
1RS6A105 R11 1M
1RS6D103 R12 10K0
1IS072BM U1 1IS072BM
1DDS0204 Z1 1DDS0204
1DDS0204 Z2 1DDS0204
