Contents
I、Insta llati on specifi cation and Rules
II、System element
III、Equipment syste ms insta llati on and te sting
3-1 Mainfra me fixed
3-2 The installation of camera s
3-3 The installation of magnetic switch on the door(M enci)
3-4 System Linked Dra wing
3-5 The function and re joining method of all kind of re cord er wire
3-6 The installation and debugging of vehicle speed signal
3-7 System debugging
IV、Manipulate
3-8 Host interf ace
3-9 The function instru ction of the video re cord er
4-1 The corre ct way to take and put the card
4-2 The corre ct way to format and restoration SD Card
V、Video Record er Technical Target
V、Video Recorder Technical Target
Number Item Technical Target
1 WVDC 9V ~ 36V (be applicable to all vehicle)
2 Rated operational current <300mA
3 Ambient Operating Range
-40
o
C ~ 85
o
C ( be applicable
to from coast to coast)
4 the humidity in the environment 20% ~ 95% RH
5 Video input 1-channel; 2-channel (1.0V
p-p/75Ω SYS:PAL/NTSC)
6 Audio Input 1-channel(frequency coverage:300-5KHZ;
frequency response:2.5dB)
7 Obligate input signal one pulse value signal (Velocity); one
switching value (footbrake)
8 Video output 1-channel (TVOUT) (1.0V p-p/75Ω
SYS:PAL/NTSC)
9 Audio output
DC12V/1A
10 Support SD Card capacity
256M - 16G
11 file format
AVI
12 Video frame rate
15 - 30 FBS(cycles per second)
13 Audio resolving capability
VGA (640X480) or QVGA (320X240)
14 Audio Dimension of frame
Length118mm×Width83mm×Height42mm
