Drivers
Anew
Naturally, like the original, the driver is built on to an 8-inch (200mm)
die-cast chassis with large rear ‘windows’ to reduce early reflections
back through the cone. Special care has been taken to marry a low
density nitrile surround to the cone to match its impedance and reduce
reflections from the cone edge.
This new polypropylene cone has been treated with mineral filling to
enables you to hear exactly how bass instruments are being played. This
is balanced by tuning the cabinet and reflex port to a very low
frequency, avoiding the ‘one-note bass’ that is typical of a lot of
bass-reflex systems. In addition, the port is strongly flared at both inlet
and outlet to smooth airflow and eradicate distortion. Bass extends
powerfully and cleanly to below 30Hz in room, which is remarkable for
this size of speaker.
Designer's Notes
08
Flux-focus
Sub-magnet
T-yoke
Main Magnet
Top Plate
High Flexibility
Progressive Spider
Large Diameter
Voice Coil
Mineral Loaded
Polypropylene Cone
Clamp Ring
Rigid Die-cast
Chassis
Low Damping
Rubber Surround
Dust Cap
Above: Exploded technical diagram for the new Mission 770 bass unit.
