INTRODUCTION OF PARTS
PRODUCT TECHNICAL PARAMETERS
MFD310
MODEL
220-240V~ 50-60Hz
RATED VOLTAGE
40W
RATED POWER
6.4 m/sec
AIR VOLUME
10 m
3
/min
MAX AIR FLOW
Control panel
Body
Base
Note: All the pictures in this manual are for explanation purpose only.
Any discrepancy betweenthe real object and the illustration in the drawing shall be subject to the real subject.
High speed of air ow
Timer:
(You can press the key to time
the fan to shut down after 1-120
min )
Body oscillating switch
Middle speed of air ow
Low speed of air ow
ON
OFF
120
30
90
60
OSC
III II I
OFF
Warning:
Do not rotate the timer counter-clockwise to “ON” from “120min”.
1. Take out the fan body and the spare parts from the box.
2. Put the front base onto rear base and join them together.
3. Pass the power cord through the ute, then insert the fan
body into the base.
Flute
4. Fix the fan body on the base with the plastic nut.
Base Installation
To Next Page
