MiTAC Pluto E220 - Page 59

5.1 HDD Security Configuration
Main Advanced Chipset Boot
Security
Save & Exit
HDD Password Description
Allow Access to Set, Modify and Clear
Hard Disk User and Master Password.
User Password need to be installed for
Enabling Security. Master Password can
Be Modified only when successfully unlocked
With Master Password in POST.
HDD PASSWORD CONFIGURATION:
Security Yes
Supported :
Security No
Enabled :
Security No
Locked :
Security No
Frozen :
HDD User Pwd Status NOT INSTALLED
HDD Master Pwd Status NOT INSTALLED
Set User Password
Item help
→←: Select Screen
↑↓: Select Item
Enter: Select
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.15.1326. Copyright (C) 2012 American Megatrends, Inc.
Field Name
Set User Password
Help
Set HDD User Password
Comment
Press Enter when selected to go into the associated Sub-Menu.
