HDD / S DD I n s t a ll a t i on
Use the HDD bracket for the HDD
installation.
Unscrew to detach the bracket
If you want to install the SATA DOM, just
remove the bracket and install the DOM to
the SATA connector.
Align the screw holes for HDD and bracket
Fix the HDD with screws on the back side
of the bracket
Finish the HDD bracket assembly
