Mitel MiVoice 4420 IP Basic Installation Guide

9
C
ONNECTORS AND INDICATORS
CHAPTER 3 GETTING STARTED
10 LINK Green, steady ON Indicates that the PRI
port is well connected
and the link is up.
OFF Indicates that the PRI
port is not well
connected and the link
is not up.
10 IN-USE Amber, steady ON Indicates that the PRI
port is in use.
OFF Indicates that the PRI
port is not connected.
10 ERROR/TROUBLE Red, steady ON Indicates that the PRI
port is not working
properly
OFF Indicates that the PRI
port is working properly
11 READY Amber, steady ON Indicates that the PRI
port is in use.
OFF Indicates that the PRI
port is not connected.
13 ETH1 - Right LED
(activity)
Green, blinking,
variable rate
Network traffic
Green, steady ON No Network traffic
OFF Not connected
13 ETH1 -Left LED
(speed)
OFF 10 Mbps
Green 100 Mbps
Yellow 1000 Mbps
14 ETH2/3/4/5/ext -Right
LED (activity)
Green blinking,
variable rate
Network Traffic
Green, steady ON No network traffic
OFF Not connected
14 ETH2/3/4/5/ext -Left
LED (speed)
OFF 10 Mbps
Green 100 Mbps
Yellow 1000 Mbps
# LED Behaviour Condition
