15
C
ONNECTING THE TELEPHONY CABLES
CHAPTER 4 INSTALLATION
Connecting the Telephony Cables
NOTE: To prevent damage to the EX Controller, make sure to connect the cables to their proper location
on the EX Controller.
1. Make sure an adequate earth ground connection has been made between the grounding screw on
the back of the EX Controller and an appropriate grounding point in your site.
WARNING: Adequate earth grounding connection of the ex controller is mandatory to avoid any
damage or injuries.
2. Wear an ESD wrist strap, ensuring it makes good contact with your bare skin.
3. Attach the ESD wrist strap end to an earth ground (unpainted bare metal spot of a grounded equip-
ment rack).
4. Make sure the circuit breakers of AC power sources used to power the EX Controller are OFF.
5. Make sure the provided power cable is connected to the EX Controller and in an appropriate AC elec-
trical outlet.
6. Connect faxes, phones or a PBX to the FXS card.
7. Connect a PBX or ISDN line to the PRI card. See Endpoint Pinout.
8. Connect a PSTN or a PBX to the FXO card.
9. Connect a PBX line to the BRI card. See BRI S/T Connection (RJ-48).
Software Installation
MX-ONE
See MiVoice MX-ONE Optional Installtions on Mitel Document Center.
MiVoice 5000
See MiVoice 5000: Installing and Configuring Mitel EX Controller and EX Gateway on Mitel Document
Center.
