266LRH / 268LRH Hedgetrimmer
21
Original Instructions Version June13
Specications
MODEL MITOX 266LRH 268LRH
Engine Type Air cooled 2-stroke gasoline engine
Model IE34F-2E
Displacement : ( cm3) 25.4 cc
Max. output 0.7 (kw) in accordance with ISO 8893
Idle speed: rpm (min –1) 2800±150
Max. power speed: rpm
(min –1)
9800
Fuel tank capacity 0.65L
Fuel Mixture (petrol 40 : Oil 1)
Carburettor Diaphragm type
Spark Plug Torch L8RTC or NGK-R BPMR7A or equivalent
Transmission Centrifugal clutch, spur gear, cam-crank
MODEL MITOX 266LRH
Dry Weight w/o shoulder strap & petrol 7.1 kg
Overall size (LxWxH) 2300mmx230mmx250mm
Reduction ratio 4 : 1
Cutting head Type Reciprocating Double blade
Pitch 30mm
Eective cut width 16 inches/ 400mm
Angle adjust range 90°(±45° from cutting head position aligned shaft)
MODEL MITOX 268 LRH
Dry Weight w/o shoulder strap & petrol 7.2 kg
Overall size (LxWxH) 2410mmx230mmx250mm
Reduction ratio 4 : 1
Cutting head Type Reciprocating Double blade
Pitch 30mm
Eective cut width 21 ½ inches/ 550mm
Angle adjust range 220°
Above specications are subject to change without notice.
