28MT Multi-Tool
7
Original Instructions Version December 15
Brushcutter Gear Case
• Remove the bolt (a) on the gear case, top up the gearbox using Lithium grease and refit the
bolt.
Gearbox Lubricant
• DO NOT force grease into the gear boxes, apply 2 or 3 pumps of grease every 15 hours of
operation.
(a)
Specification
EX-BC (When used as a Brushcutter)
Weight (Power Unit & Attachment) 6.51kg
Weight (Attachment Only) 1.88Kg
Reduction ratio 22 :17
Cutting head Cutting
width
3 tooth
blade
255mm
Nylon
head
415mm
3 tooth blade
thickness
1.4mm
Cutting line diameter 2.4mm
Max. blade rotation
speed:
7500 rpm (min –1)
Rotation direction Counter clockwise (as seen from above)
