496
5. PARAMETERS
5.12 (T) Multi-function input terminal parameters
5.12.8 Input terminal function selection
Use the following parameters to select or change the input terminal functions.
*1 The initial value is for standard models and IP55 compatible models.
*2 The initial value is for separated converter types.
Input terminal function assignment
• Use Pr.178 to Pr.189 to set the functions of the input terminals.
• Refer to the following table and set the parameters.
Pr. Name
Initial
value
Initial signal Setting range
178
T700
STF terminal
function selection
60 STF (Forward rotation command)
0 to 20, 22 to 28, 37, 42 to 48, 50 to 53, 57 to 60,
62, 64 to 74, 76, 77 to 80, 85, 87 to 89, 92 to 96,
9999
179
T701
STR terminal
function selection
61 STR (Reverse rotation command)
0 to 20, 22 to 28, 37, 42 to 48, 50 to 53, 57 to 59,
61, 62, 64 to 74, 76, 77 to 80, 85, 87 to 89, 92 to
96, 9999
180
T702
RL terminal function
selection
0 RL (Low-speed operation command)
0 to 20, 22 to 28, 37, 42 to 48, 50 to 53, 57 to 59,
62, 64 to 74, 76, 77 to 80, 85, 87 to 89, 92 to 96,
9999
181
T703
RM terminal function
selection
1 RM (Middle-speed operation command)
182
T704
RH terminal function
selection
2 RH (High-speed operation command)
183
T705
RT terminal function
selection
3 RT (Second function selection)
184
T706
AU terminal function
selection
4 AU (Terminal 4 input selection)
185
T707
JOG terminal
function selection
5 JOG (Jog operation selection)
186
T708
CS terminal function
selection
6
CS (Selection of automatic restart after
instantaneous power failure / flying start)
187
T709
MRS terminal
function selection
24
*1
MRS (Output stop)
10
*2
X10 (Inverter run enable)
188
T710
STOP terminal
function selection
25 STP (STOP) (Start self-holding selection)
189
T711
RES terminal
function selection
62 RES (Inverter reset)
Pr. Name
Initial
value
Setting range Description
699
T740
Input terminal filter 9999
5 to 50 ms Set the time delay for the input terminal response.
9999 No filter for the input terminal
Setting
Signal
name
Function Related parameter
Refer to
page
0RL
Pr.59 = 0 (initial value) Low-speed operation command
Pr.4 to Pr.6, Pr.24 to Pr.27,
Pr.232 to Pr.239
391
Pr.59 ≠ 0
*1
Remote setting (setting clear) Pr.59 359
Pr.270 = 1, 3, 11, 13
*2
Stop-on-contact selection 0 Pr.270, Pr.275, Pr.276 546
1RM
Pr.59 = 0 (initial value)
Middle-speed operation
command
Pr.4 to Pr.6, Pr.24 to Pr.27,
Pr.232 to Pr.239
391
Pr.59 ≠ 0
*1
Remote setting (deceleration) Pr.59 359
2RH
Pr.59 = 0 (initial value) High-speed operation command
Pr.4 to Pr.6, Pr.24 to Pr.27,
Pr.232 to Pr.239
391
Pr.59 ≠ 0
*1
Remote setting (acceleration) Pr.59 359
3RT
Second function selection
Pr.44 to Pr.51, Pr.450 to
Pr.463, Pr.569, Pr.832,
Pr.836, etc.
500
Pr.270 = 1, 3, 11, 13
*2
Stop-on-contact selection 1 Pr.270, Pr.275, Pr.276 546
4 AU Terminal 4 input selection Pr.267 473
5 JOG Jog operation selection Pr.15, Pr.16 390
