PRECAUTIONS FOR USE OF THE INVERTER
3.5 Countermeasures against deterioration of
the 400 V class motor insulation
In the PWM type inverter, a surge voltage attributable to wiring constants is generated at the motor terminals. Especially in a
400 V class motor, the surge voltage may deteriorate the insulation. When the 400 V class motor is driven by the inverter,
consider the following countermeasures:
Countermeasures for induction motors
It is recommended to take one of the following countermeasures:
Rectifying the motor insulation and limiting the PWM carrier frequency according
to the wiring length
For the 400 V class motor, use an insulation-enhanced motor.
Specifically,
• Order a "400 V class inverter-driven insulation-enhanced motor".
• For the dedicated motor such as the constant-torque motor and low-vibration motor, use an "inverter-driven dedicated
motor".
•Set Pr.72 PWM frequency selection as indicated below according to the wiring length.
Suppressing the surge voltage on the inverter side
• For the FR-F846-01160(55K) or lower, connect the surge voltage suppression filter (FR-ASF-H/FR-BMF-H) to the
output side.
• For the FR-F846-01800(75K) or higher, connect the sine wave filter (MT-BSL/BSC) to the output side.
Countermeasures for PM motors
• When the wiring length exceeds 50 m, set "9" (6 kHz) or less in Pr.72 PWM frequency selection.
NOTE
• For the details of Pr.72 PWM frequency selection, refer to the FR-F800 Instruction Manual (Detailed).
• For the details of the surge voltage suppression filter (FR-ASF-H/FR-BMF-H), refer to the Instruction Manual of each option.
• A surge voltage suppression filter (FR-ASF-H/FR-BMF-H) can be used under V/F control and Advanced magnetic flux vector
control.
A sine wave filter (MT-BSL/BSC) can be used under V/F control. Do not use the filters under different control modes.
Wiring length
50 m or shorter 50 m to 100 m Longer than 100 m
Pr.72 PWM frequency selection 15 (14.5 kHz) or lower 9 (9 kHz) or lower 4 (4 kHz) or lower
