5.13 (G) Control parameters
Setting of base frequency voltage (Pr.19)
•For Pr.19 Base frequency voltage, set the base voltage (rated motor voltage, etc.).
• When it is set lower than the power supply voltage, maximum output voltage of the inverter will be the voltage set in Pr.19.
• Pr.19 can be used in following cases.
• When the Advanced magnetic flux vector control or PM motor control is selected, Pr.3, Pr.47 and Pr.19 will become
disabled, and Pr.83 and Pr.84 will become enabled. However, S-pattern curve with Pr.29 Acceleration/deceleration
pattern selection = "1" (S-pattern acceleration/deceleration A) will make Pr.3 or Pr.47 enabled. (S-pattern curve at the
time of the PM motor control is the rated frequency of the motor.)
• When Pr.71 Applied motor = "2" (adjustable 5 points V/F), setting for Pr.47 will become disabled. Also, Pr.19 cannot be
set to "8888" or "9999".
• Changing the terminal assignment using Pr.178 to Pr.189 (Input terminal function selection) may affect the other
functions. Set parameters after confirming the function of each terminal.
Pr.14 Load pattern selection page 541
Pr.29 Acceleration/deceleration pattern selection page 194
Pr.71 Applied motor page 351
Pr.83 Rated motor voltage, Pr.84 Rated motor frequency page 353
Pr.178 to Pr.189 (Input terminal function selection) page 343
(a) Regenerative driving (continuous regeneration, etc.) is performed often
Output voltage will get higher than the specification during the regenerative driving, which may cause overcurrent trip (E.OC[]) by the
increase in motor current.
(b) When the fluctuation of power supply voltage is high
When the power supply voltage exceeds the rated voltage of the motor, fluctuation of rotation speed or overheating of motor may
occur due to excessive torque or increase in motor current.
