12
1 Remove the catechin air filter.
2 Remove the air cleaning filter.
REPLACEMENT OF THE AIR CLEANING FILTER
When the capacity is lowered because of dirt, etc., it is necessary to replace the air cleaning filter.
Air cleaning filter replacement (about once every year)
3 Attach a new air cleaning filter. Fix the filter
with the tabs securely.
4 Install the catechin air filter.
Be sure to install its both ends into the tabs
as shown below.
5 Securely close the front grille.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Air cleaning filter
• If the air cleaning filter is clogged, it may lower the unit’s capacity or cause condensation at the air outlet.
• The air cleaning filter is disposable. The standard usable term is about 1 year.
Optional parts Optional parts are available from your local dealer.
Name of parts
AIR CLEANING FILTER
(Anti-Allergy Enzyme Filter)
Parts number MAC-415FT-E
CLEANING THE
AIR CLEANING FILTER
Cleaning the air cleaning filter (about once every 3 months)
1 Remove the catechin air filter.
2 Remove the air cleaning filter.
3 Soak the filter together with its frame in luke-
warm water and wash it.
■ If the dirt is noticeable, use a solution of mild deter-
gent diluted in lukewarm water.
■ If hot water (50°C or more) is used, the filter may
be deformed.
■ Do not use a scrubbing brush or sponge. This may
damage the surface of the filter.
■ Do not use a chlorine detergent.
4 After rinsing with water/lukewarm water,
shake off the excess water and dry the filter
well in the shade.
■ Do not expose the filter to direct sunlight or heat
from a fire when drying it.
5 Attach the air cleaning filter. Fix the filter with
the tabs securely.
6 Install the catechin air filter. (Securely install
its tabs.)
7 Securely close the front grille.
Open the front grille
Catechin air filter
Open the front grille
Catechin air filter
Install.
Catechin air filter
Air cleaning filter
Catechin air filter
Air cleaning filter
Install.
HM05B040_MFZ-KA_en.p65 05.4.6, 7:12 PM12
