Mitsubishi Electric Mr.Slim PAR-30MAA User Manual

63
Service
F1 F2 F3 F4
Lossnay
Lossnay
Return:
IU address
Lossnay address
IU address
Lossnay address
Sending data
Setting completed
Lossnay
Lossnay
Return:
IU address
Lossnay address
IU address
Lossnay address
Collecting data
Unit not exist
Lossnay
Lossnay
Return:
IU address
Lossnay address
IU address
Lossnay address
Deleting
Request rejected
[
4
]
Enter the addresses of the indoor unit and the LOSSNAY unit to be inter-
locked, with the
F1
through F4 buttons, select "Set" in the "Function",
and press the button to save the settings.
"Sending data" will appear on the screen.
If the setting is successfully completed, "Setting completed" will appear.
To make LOSSNAY interlock setting
[
5
]
Enter the address of the indoor unit to which the remote controller is con-
nected, select "Conf" in the "Function", and press the button.
"Collecting data" will appear on the screen. If the signal is received correctly,
the indoor unit address and LOSSNAY address will appear. "--" will appear when
no LOSSNAY unit is found. "Unit not exist" will appear if no indoor units that are
correspond to the entered address are found.
To search for the LOSSNAY address
[
6
]
To delete the interlocked setting between LOSSNAY unit and the indoor
units
to which the remote controller is connected, enter the indoor unit address
and LOSSNAY address with the F1 through F4 buttons, select "Del." in
the "Function", and press the button. "Deleting" will appear.
The screenwill return to the search result screen if the deletion is successfully
completed. "Unit not exist" will appear if no indoor units that are correspond to
the entered address are found. If deletion fails, "Request rejected" will appear on
the screen.
To delete the interlock setting
