PART NAMES AND FUNCTIONS
2
ACCESSORIES
MXZ-2D33VA
MXZ-2D40VA
MXZ-2D53VA
MXZ-2D53VAH
Air inlet
Air outlet
Drain outlet
Piping
Drain hose
(Back and side)
Model
MXZ-2D33VA
MXZ-2D40VA
MXZ-2D53VA
MXZ-4D83VA
MXZ-5D102VA
MXZ-3D54VA
MXZ-3D68VA
MXZ-4D72VA
Drain socket 1 1
Drain cap 2
Air outlet
Drain outlet
Air inlet
(Back and side)
MXZ-3D54VA
MXZ-3D68VA
MXZ-4D72VA
MXZ-4D83VA
MXZ-5D102VA
Air outlet
Drain outlet
Air inlet
(Back and side)
OBH626B
