6
Outdoor model MXZ-2D40VA
Outdoor unit power supply
Single phase
230 V, 50 Hz
System
Indoor units number 1 to 2
Piping total length m Max. 30
Connecting pipe length m Max. 20
Height difference (Indoor ~ Outdoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Height difference (Indoor ~ Indoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Function Cooling Heating
Capacity Rated frequency (Min.-Max.)
2 kW 4.0 (1.1 - 4.3) 4.5 (1.0 - 4.8)
Breaker capacity A 15
Electrical
data
Power input (Total) 1, 2 W 970
Running current (Total)
1, 2 A 4.7
Power factor (Total)
1, 2% 90
Starting current (Total)
1, 2 A 4.7
Coeff cient of performance (C.O.P) (Total)
1, 2 4.12 4.64
Compressor
Model KNB092FFDHC
Output W 1,100
Current
1, 2 A 4.4 4.2
Refrigeration oil (Model) L 0.32 (NEO22)
Fan
motor
Model RC0J50-FA
Current
1, 2 A 0.35
Dimensions W x H x D mm 800 x 550 x 285
Weight kg 34
Special
remarks
Air f ow (Rated) m
3
/h 1,752 1,662
Sound level (Rated) dB(A) 49 50
Fan speed (Rated) rpm 840 800
Refrigerant f lling capacity (R410A) kg 1.3
1 Measured under rated operating frequency.
2 When connected with below indoor units.
MSZ-EF18VE + MSZ-EF22VE
NOTE: Test conditions are based on ISO 5151. (Refrigerant piping length (one way): 5 m)
COOLING INDOOR Dry-bulb temperature 27.0 °C Wet-bulb temperature 19.0 °C
OUTDOOR Dry-bulb temperature 35.0 °C Wet-bulb temperature 24.0 °C
HEATING INDOOR Dry-bulb temperature 20.0 °C
OUTDOOR Dry-bulb temperature 7.0 °C Wet-bulb temperature 6.0 °C
