10
Outdoor model MXZ-2E53VAHZ
Outdoor unit power supply
Single phase
220 -230 - 240 V, 50 Hz
4
System
Indoor units number 2
Piping total length m Max. 30
Connecting pipe length m Max. 20
Height difference (Indoor ~ Outdoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Height difference (Indoor ~ Indoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Function Cooling Heating
Capacity Rated frequency (Min.-Max.)
2 kW 5.3 (1.1 - 6.0) 6.4 (1.0 - 7.0)
Breaker capacity A 16/25
3
Electrical
data
Power input (Total) 1, 2 W 1,290 1,360
Running current (Total)
1, 2 A 5.9 - 5.7 - 5.4 6.2 - 6.0 - 5.7
Power factor (Total)
1, 2% 98
Starting current (Total)
1, 2 A 6.0
Coeffi cient of performance (C.O.P) (Total)
1, 2 4.11 4.71
Compressor
Model SNB220FAGMC
Output W 1,400
Current
1, 2 A 5.3 5.5
Refrigeration oil (Model) L 0.7 (FV50S)
Fan
motor
Model
E1
: SIC-81FW-D888-9, SIC-88FWJ-D888-1
ER1
: SIC-88FWJ-D888-1
E2
,
ER2
: SIC-88FWJ-D888-4
Current
1, 2 A 0.3
Dimensions W x H x D mm 950 x 796 x 330
Weight kg 61
Special
remarks
Air fl ow (Rated) m
3
/h 2,820 2,820
Sound level (Rated) dB(A) 45 47
Fan speed (Rated) rpm 520 520
Refrigerant fi lling capacity (R410A) kg 2.0
1 Measured under rated operating frequency.
2 When connected with below indoor units.
3 When the amount of current exceeds the allowed value.
MSZ-EF18VE + MSZ-EF35VE
4
220 and 240 V are only -
E2
and -
ER2
.
NOTE: Test conditions are based on ISO 5151. (Refrigerant piping length (one way): 5 m)
COOLING INDOOR Dry-bulb temperature 27.0°C Wet-bulb temperature 19.0°C
OUTDOOR Dry-bulb temperature 35.0°C Wet-bulb temperature 24.0°C
HEATING INDOOR Dry-bulb temperature 20.0°C
OUTDOOR Dry-bulb temperature 7.0°C Wet-bulb temperature 6.0°C
