11
Outdoor model MXZ-4E83VAHZ
Outdoor unit power supply
Single phase
220 -230 - 240 V, 50 Hz
4
System
Indoor units number 2 to 4
Piping total length m Max. 70
Connecting pipe length m Max. 25
Height difference (Indoor ~ Outdoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Height difference (Indoor ~ Indoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Function Cooling Heating
Capacity Rated frequency (Min.-Max.)
2 kW 8.3 ( 3.5 - 9.2 ) 9.0 ( 3.5 - 11.6 )
Breaker capacity A 25/30
3
Electrical
data
Power input (Total) 1, 2 W 2,250 1,900
Running current (Total)
1, 2 A 10.3 - 9.9 - 9.5 8.7 - 8.3 - 8.0
Power factor (Total)
1, 2% 99
Starting current (Total)
1, 2 A 9.9
Coeffi cient of performance (C.O.P) (Total)
1, 2 3.68 4.73
Compressor
Model MNB33FBTMC-L
Output W 2,200
Current
1, 2 A 9.30 7.60
Refrigeration oil (Model) L 1.10 (FV50S)
Fan
motor
Model
E1
,
ER1
,
E2
,
ER2
: SIC-81FW-D888-9,
SIC-88FWJ-D888-1
E3
,
ER3
: SIC-88FWJ-D888-4
Current
1, 2 A 0.3
Dimensions W x H x D mm 950 x 1,048 x 330
Weight kg 87
Special
remarks
Air fl ow (Rated) m
3
/h 3,780 4,620
Sound level (Rated) dB(A) 53 57
Fan speed (Rated) rpm 650 770
Refrigerant fi lling capacity (R410A) kg 3.9
1 Measured under rated operating frequency.
2 When connected with indoor units below.
3 When the amount of current exceeds the allowed value.
MSZ-EF18VE + MSZ-EF18VE + MSZ-EF22VE + MSZ-EF25VE
4
220 and 240 V are only -
E3
and -
ER3
.
NOTE: Test conditions are based on ISO 5151. (Refrigerant piping length (one way): 5 m)
COOLING INDOOR Dry-bulb temperature 27.0 °C Wet-bulb temperature 19.0 °C
OUTDOOR Dry-bulb temperature 35.0 °C Wet-bulb temperature 24.0 °C
HEATING INDOOR Dry-bulb temperature 20.0 °C
OUTDOOR Dry-bulb temperature 7.0 °C Wet-bulb temperature 6.0 °C
