Questions and Answers

J
jessicaleeNov 27, 2025
Why is LED2 on my Mitsubishi Electric Controller FTC (Main) off?
- C
  Catherine HowardNov 27, 2025
  When LED1 on FTC (Main) is also off, the possible causes are: * The outdoor unit is not supplied at the rated voltage. Check the voltage across the terminals L and N or L3 and N on the outdoor power board. When the voltage is not 220 to 240 V AC, check wiring of the outdoor unit and of the breaker. When the voltage is at 220 to 240 V AC, check the voltage across the outdoor unit terminals S1 and S2. * Defective outdoor controller circuit board. Check the voltage across the outdoor unit terminals S1 and S2. When the voltage is not 220 to 240 V AC, check the fuse on the outdoor control board and check for faulty wiring. When the voltage is 220 to 240 V AC, check the voltage across the indoor unit terminals S1 and S2. * FTC (Main) is not supplied with 220 to 240V AC. Check the voltage ...
E
Emily BrownAug 25, 2025
Why is my Mitsubishi Electric PAC-IF081B-E noisy?
- P
  Patrick JordanAug 26, 2025
  A noisy water circulation pump in your Mitsubishi Electric Controller system is caused by air in the water circulation pump. Use manual and automatic air vents to remove air from the system. Top up water if necessary to achieve 1 bar on primary circuit.
S
Scott RivasAug 29, 2025
What does it mean if LED4 on Mitsubishi Electric Controller FTC (Main) is blinking?
- E
  espinozapeterAug 29, 2025
  If LED4 on the FTC (Main) of your Mitsubishi Electric Controller is blinking, it indicates a problem with the SD memory card: * Full of data: Move or delete data, or replace microSD memory card with a new one. * Write-protected: Release the write-protect switch. * NOT formatted: Refer to "4.11 Using microSD memory card". * Formatted in NTFS file system: FTC is not compatible with NTFS flie system. Use a microSD memory card formatted in FAT file system.
C
Christopher JamesAug 30, 2025
Why does my Mitsubishi Electric Controller have no hot water at the hot tap?
- J
  Julia EdwardsAug 30, 2025
  If there's no hot water at the tap with your Mitsubishi Electric Controller, the possible causes are: * Cold main off: Check and open stop cock. * Strainer (local supply) blocked: Isolate water supply and clean strainer.
L
linda10Sep 19, 2025
Why doesn't the cooling system cool down to the set temperature with Mitsubishi Electric PAC-IF081B-E Controller?
- L
  Lauren PetersSep 22, 2025
  If the cooling system on your Mitsubishi Electric Controller isn't cooling down to the set temperature, it could be due to: * When the water in the circulation circuit is unduly hot, Cooling mode starts with a delay for the protection of the outdoor unit. Normal operation. * When the outdoor temperature is lower than the preset temperature below which the freeze stat. function is activated, Cooling mode does not start running. To run Cooling mode overriding the freeze stat. function, adjust the preset temperature below which the freeze stat. function is activated.
A
allison60Sep 16, 2025
Why is FTC unit running in the DHW mode after power recovery with Mitsubishi Electric PAC-IF081B-E Controller?
- T
  Terry HicksSep 16, 2025
  The FTC unit is designed to run in an operation mode with a higher priority (i.e. DHW mode in this case) at power recovery. Normal operation. After the DHW max. operation time has elapsed or the DHW max. temperature has been reached, the DHW mode switches to the other mode (ex. heating mode).
A
ashley08Sep 18, 2025
Why is cooling mode NOT available on my Mitsubishi Electric Controller?
- M
  Melissa FlemingSep 18, 2025
  If cooling mode is not available on your Mitsubishi Electric Controller, DIP SW2-4 is OFF. Turn DIP SW2-4 to ON. (Refer to “5.1 DIP switch functions” in this manual.)
K
Kelly DyerSep 9, 2025
Why does water discharge from the pressure relief valve (Primary circuit) in Mitsubishi Electric PAC-IF081B-E Controller?
- J
  Jonathan CruzSep 9, 2025
  If water is discharging from the pressure relief valve (primary circuit) in your Mitsubishi Electric Controller, it could be due to: * If continual – pressure relief valve may be damaged. Turn the handle on the pressure relief valve to check for foreign objects in it. If the problem is not still solved, replace the pressure relief valve with a new one. * If intermittent – expansion vessel charge may have reduced/bladder perished. Check pressure in expansion vessel. Recharge to 1 bar if necessary. If bladder perished replace expansion vessel with a new one.
A
Anthony TuckerSep 7, 2025
Why does only Zone 2 not reach the set temperature in Mitsubishi Electric PAC-IF081B-E Controller?
- S
  Steven YoungSep 7, 2025
  For a Mitsubishi Electric Controller with 2-zone temperature control, if only Zone 2 isn't reaching the set temperature, consider these factors: * When Zone 1 and Zone 2 are both in heating mode, the hot water temperature in Zone 2 does not exceed that in Zone 1. Normal operation no action necessary. * Faulty wiring of motorized mixing valve. Refer to "4.7 Wiring for 2-zone temperature control". * Faulty installation of motorized mixing valve. Check for correct installation. (Refer to the manual included with each motorized mixing valve.) * Incorrect setting of running time. Check for correct setting of running time. * Motorized mixing valve failure. Inspect the mixing valve.
J
Jennifer ClineSep 8, 2025
Why does the room temperature rise during DHW operation with Mitsubishi Electric PAC-IF081B-E Controller?
- J
  Jeffrey BoydSep 8, 2025
  If the room temperature rises during DHW operation with your Mitsubishi Electric Controller, the 3-way valve may have failed. Check the 3-way valve.
