PART NAMES AND FUNCTIONS
● Indoor Unit
PKFY-P20VAM-E
PKFY-P25VAM-E
Air intake grille
Air intake
Guide vane
Air Outlet
Auto Vane
Filter
● Operation buttons
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
Set Temperature buttons
Down
Up
Timer Menu button
(Monitor/Set button)
Mode button (Return button)
Set Time buttons
Back
Ahead
Timer On/Off button
(Set Day button)
Opening the
door.
ON/OFF button
Fan Speed button
Filter button
(<Enter> button)
Test Run button
Check button (Clear button)
Airflow Up/Down button
Louver button
( Operation button)
To preceding operation
number.
Ventilation button
(
Operation button)
To next operation number.
On the controls are set, the same operation mode can be repeated by simply pressing the ON/OFF button.
● Wired remote controller
OC309A---1.qxp 06.7.7 3:47 PM Page 6

Mitsubishi Electric PKFY-P20VAM-E Specifications

General

Category	Air Conditioner
Power Supply	220-240 V, 50 Hz
Refrigerant	R410A
Outdoor Unit Dimensions (HxWxD)	550 x 780 x 285 mm
Outdoor Unit Noise Level	49 dB(A)
