6
-
(2) Outdoor unit
Models All models
2-16×12
Drain holes (ø20)
138.4
40
˚
61.9
18.9165.1510104.9
439.1
111.4
99.4
349.5
313.1
43.1
290
12
50
350
23.5312.5
14
33.5
40
˚
42.595.9
14
540
780
Service valve (Liquid)
Flare connection ø6.35 (1/4'')
Service valve (Gas)
Flare connection
20, 28: ø9.52 (3/8'')
40: ø12.7 (1/2'')
Terminal block
