7-14
Vehicle care and maintenance
7
5. Put the duct and upper cover back on in its original posi-
tion. For details, refer to “Removing and installing the
upper cover and duct” on page 7-14.
Removing and installing the upper cover and
duct
To replace the air cleaner filter, remove the upper cover and
duct.
To remove
1. Remove the clips (A), and then remove the upper cover
(B).
WARNING
!
● Turn the ignition switch to the “OFF” position or
put the operation mode in OFF.
Make sure that your clothes cannot be caught by the
fan or drive belt. Personal injury could result.
BK0150700US.book 14 ページ ２０１２年３月２２日 木曜日 午後６時４６分
To Next Page
