Vehicle care and maintenance
7-41
7
Engine compartment
In the engine compartment, the fuse block is located as shown
in the illustration.
Fuse load capacities
N00954800172
This fuse list shows the names of the electrical systems and
their fuse capacities.
There are spare fuses in the fuse block cover in the engine
compartment. Always replace a blown fuse with one of the
same capacity as the original.
Passenger compartment fuse location table
1- Push the lock lever.
2- Remove the fuse block cover.
Passenger compartment fuse location
Sub fuse block
Main fuse block
BK0150700US.book 41 ページ ２０１２年３月２２日 木曜日 午後６時４６分
