9-8
Specifications
9
Engine specifications
N01147700181
Item 2.4 liter 3.8 liter
Engine model 4G69 6G75
Engine displacement 145.1 CID (2,378 cm³) 233.6 CID (3,828 cm³)
No. of cylinders and cylinder arrangement 4 in-line 6-V60°
Bore 3.43 in (87.0 mm) 3.74 in (95.0 mm)
Stroke 3.93 in (100.0 mm) 3.54 in (90.0 mm)
Compression ratio 9.5 10.5
Thermostat valve opening temperature 179.6 °F (82.0 °C)
Spark plugs NGK LZFR6AI IFR6B-K
Spark plug gap .028 to.031 in (0.7 to 0.8 mm)
Firing order 1-3-4-2 1-2-3-4-5-6
Ignition timing, idle speed, mixture Refer to the “Vehicle emission control information label” inside panel of the engine hood.
