HOW TO READ THIS MANUAL
Disassembly diagram (example)
Sequence
1. Cover, Bolt, Washer (part name)
2. Output shaft (part name)
Suggestion for disassembly
(1) Output shaft removal
Unit: mm (in.)
A
0.020 to 0.105
Clearance between
(0.00079 to 0.00413)
cylinder and piston
0.15
B
(0.0059)
A: Standard value B: Repair or service limit
Disassembly sequence
Each disassembly diagram is followed
by Disassembly sequence and
Suggestions for disassembly.
