1-5
Ref. Model Gasoline-engine
FG15N FG18N
No. Truck
Diesel-engine
(FD15N) (FD18N)
Item
Truck
A Maximum lift 3000 (118)
B Free lift 115 (4.5)
C Fork spread (outside) 200 to 920 (7.9 to 36.2)
D Fork length 920 (36.2)
E Tilt angle (forward – backward) 6° – 12°
F Overall length 3180 (125.2) 3221 (126.8)
G Overall width (outside of tires)
Single tire 1065 (41.9)
Dual tire 1330 (52.4)
H Overall height (to top of mast lowered) 1995 (78.5)
I Overall height (to top of overhead guard) 2065 (81.3)
J Overall height (mast extended) 4055 (159.6)
K Tread (front)
Single tire 890 (35)
Dual tire 1025 (40.4)
L Tread (rear) 900 (35.4)
M Wheelbase 1400 (55.1)
N Front overhang 400 (15.7)
O Minimum turning radius 1950 (76.8) 1980 (78)
P Underclearance (at frame) 150 (5.9)
GENERAL INFORMATION
Technical Data
Unit: mm (in.)
