Mitsubishi FR-S520-0.1K to 3.7K(-R)(-C) - Page 11

6
FR-S520S-0.1K to 1.5K (-R) (-C)
Power supply
NFB
R
S
Motor
IM
Earth
(
Ground
)
U
V
W
MC
Remarks
• To ensure safety, connect the power input to the inverter via a magnetic
contactor and earth leakage circuit breaker or no-fuse breaker, and use the
magnetic contactor to switch power on-off.
• The output is three-phase 200V.
