9-2 Heating and air conditioning
NOTE:
The heater uses the heat produced by the engine
coolant. Warm air is, therefore, not available until
the coolant temperature becomes sufficiently high.
When you use the heater while warming up the
engine or parking, turn ON the cold start switch to
help warm the interior more quickly.
1 Control panel
Fan switch
Temperature control lever
Mode selector lever
Air selector lever
Fresh air bypass lever
• Fan switch
Fan switch allows you to select 4 fan speeds. Select
the desired speed.
OFF: Turned off
: Breeze
:Weak
:Medium
:Strong
• Temperature control lever
Slide lever toward the high temperature side
(orange colored) for warmer air.
Heater
Z00549
Z11871
Z11872
